SRRIFF - Fast Foot
Showing 1-10 of 24
Per page:1-10 of 24
Item Code | Foot Material | Color | Maximum Hole Diameter | Maximum Panel Thickness | Base Height | Maximum Base Diameter | Base Diameter | Type | Mount Type | Material Flammability Standard | Minimum Base Diameter | Minimum Hole Diameter | Material | Overall Diameter | Grommet Material | UL/CSA Description | Rivet Material | Minimum Panel Thickness | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
FF-006-P4X7B | TPE | Black | 4.2 mm | 2.0 | 0.24 in | 15.0 mm | 0.590 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 14.0 mm | 4.1 mm | TPE | 14.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 1.0 | |
FF-006-P4X6B | TPE | Black | 4.2 mm | 1.0 | 0.24 in | 15.0 mm | 0.590 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 14.0 mm | 4.1 mm | TPE | 14.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 0.6 | |
FF-006-P4X8B | TPE | Black | 4.2 mm | 3.1 | 0.24 in | 15.0 mm | 0.590 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 14.0 mm | 4.1 mm | TPE | 14.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 2.0 | |
FF-001B | TPE | Black | 5.1 mm | 2.3 | 0.550 in | 24.0 mm | 0.950 in | 1 | Drive Screw | UL94 HB;UL94 V-2 | 20.0 mm | 5.0 mm | TPE | 20.0 mm | Nylon 6 | UL E80017 | POM | 1.0 | |
FF-008-P4X7B | TPE | Black | 4.2 mm | 2.8 | 0.24 in | 21.0 mm | 0.830 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 20.0 mm | 4.1 mm | TPE | 20.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 1.9 | |
FF-008-P4X8B | TPE | Black | 4.2 mm | 4.0 | 0.24 in | 21.0 mm | 0.830 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 20.0 mm | 4.1 mm | TPE | 20.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 2.9 | |
FF-009-P4X6B | TPE | Black | 4.2 mm | 0.8 | 0.31 in | 21.0 mm | 0.830 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 20.0 mm | 4.1 mm | TPE | 20.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 0 in | |
FF-003-P3X5.5B | TPE | Black | 3.2 mm | 1.8 | 0.39 in | 14.2 mm | 0.790 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 13.5 mm | 3.1 mm | TPE | 13.5 mm | Nylon 6 | UL E80017 | Nylon 6 | 0.8 | |
FF-009-P4X7B | TPE | Black | 4.2 mm | 2.0 | 0.31 in | 21.0 mm | 0.830 in | 2 | Push Rivet | UL94 HB;UL94 V-2 | 20.0 mm | 4.1 mm | TPE | 20.0 mm | Nylon 6 | UL E80017 | Nylon 6 | 0.8 |
Per page:
1-10 of 24
1–5 of 24 variants
Per page:
FF-006-P4X7B
Foot Material
TPE
Color
Black
Maximum Hole Diameter
4.2 mm
Maximum Panel Thickness
2.0
FF-006-P4X6B
Foot Material
TPE
Color
Black
Maximum Hole Diameter
4.2 mm
Maximum Panel Thickness
1.0
FF-006-P4X8B
Foot Material
TPE
Color
Black
Maximum Hole Diameter
4.2 mm
Maximum Panel Thickness
3.1
FF-001B
Foot Material
TPE
Color
Black
Maximum Hole Diameter
5.1 mm
Maximum Panel Thickness
2.3
Per page:
1–5 of 25
