SR13SP - Round Nylon Through Spacers
Showing 1-10 of 149
Per page:1-10 of 149
Item Code | Color | Spacer Length | Outside Diameter | Maximum Operating Temperature | Spacer Shape | Material Flammability Standard | Screw Size | Minimum Operating Temperature | Material | Overall Length | Inside Diameter | Internal Thread Size | Mounting Method | Type | Thickness | Finish | Head Diameter | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
13SP005 | Natural | 6.4 | 0.188 | 185 | Round | UL94 V-2 | #2, M2 | -40 | Nylon 6/6 | 0.250 in | 0.091 | - | - | - | - | - | - | |
13SP041 | Natural | 6.4 | 0.250 | 185 | Round | UL94 V-2 | #6, M3.5 | -40 | Nylon 6/6 | 0.250 in | 0.140 | - | - | - | - | - | - | |
13SP033 | Natural | 3.2 | 0.250 | 185 | Round | UL94 V-2 | #6, M3.5 | -40 | Nylon 6/6 | 0.125 in | 0.140 | - | - | - | - | - | - | |
13SP037 | Natural | 4.8 | 0.250 | 185 | Round | UL94 V-2 | #6, M3.5 | -40 | Nylon 6/6 | 0.188 in | 0.140 | - | - | - | - | - | - | |
13SP074 | Natural | 19.0 | 0.250 | 185 | Round | UL94 V-2 | #8, M4 | -40 | Nylon 6/6 | 0.750 in | 0.171 | - | - | - | - | - | - | |
13SP062 | Natural | 14.3 | 0.250 | 185 | Round | UL94 V-2 | #8, M4 | -40 | Nylon 6/6 | 0.563 in | 0.171 | - | - | - | - | - | - | |
13SP055 | Natural | 12.7 | 0.250 | 185 | Round | UL94 V-2 | #2, M2 | -40 | Nylon 6/6 | 0.500 in | 0.091 | - | - | - | - | - | - | |
13SP105 | Natural | 7.9 | 0.313 | 185 | Round | UL94 V-2 | #8, M4 | -40 | Nylon 6/6 | 0.313 in | 0.171 | - | - | - | - | - | - | |
13SP097 | Natural | 4.7 | 0.313 | 185 | Round | UL94 V-2 | #8, M4 | -40 | Nylon 6/6 | 0.188 in | 0.171 | - | - | - | - | - | - |
Per page:
1-10 of 149
1–5 of 149 variants
Per page:
13SP005
Color
Natural
Spacer Length
6.4
Outside Diameter
0.188
Maximum Operating Temperature
185
13SP041
Color
Natural
Spacer Length
6.4
Outside Diameter
0.250
Maximum Operating Temperature
185
13SP033
Color
Natural
Spacer Length
3.2
Outside Diameter
0.250
Maximum Operating Temperature
185
13SP037
Color
Natural
Spacer Length
4.8
Outside Diameter
0.250
Maximum Operating Temperature
185
Per page:
1–5 of 150
