SRLCBS-L - Screw Mount Locking Circuit Board Support
Showing 1-6 of 6
Per page:1-6 of 6
Item Code | Material Flammability Standard | Hole A Fix Type | Color | Hole Diameter A | Spacer Length | Hole B Fix Type | Mounting Hole Diameter | Mounting Hole Center Distance | Length | Minimum Operating Temperature | Thread Size | Material | Locking Head Height A | Base Height | Maximum Panel Thickness A | Maximum Operating Temperature | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LCBS-L-9-01 | UL94 V-2 | Snap Lock | Natural | 3.2 mm | 14.3 mm | Hole Fix | 3.5 mm | 13.0 mm | 21.5 mm | -40 | #4, M3 | Nylon 6/6 | 10.0 mm | 1.5 mm | 1.57 mm | 85 | |
LCBS-L-10-01 | UL94 V-2 | Snap Lock | Natural | 3.2 mm | 15.9 mm | Hole Fix | 3.5 mm | 13.0 mm | 21.5 mm | -40 | #4, M3 | Nylon 6/6 | 10.0 mm | 1.5 mm | 1.57 mm | 85 | |
LCBS-L-6-01 | UL94 V-2 | Snap Lock | Natural | 3.2 mm | 9.5 mm | Hole Fix | 3.5 mm | 13.0 mm | 21.5 mm | -40 | #4, M3 | Nylon 6/6 | 10.0 mm | 1.5 mm | 1.57 mm | 85 | |
LCBS-L-5-01 | UL94 V-2 | Snap Lock | Natural | 3.2 mm | 7.6 mm | Hole Fix | 3.5 mm | 13.0 mm | 21.5 mm | -40 | #4, M3 | Nylon 6/6 | 10.0 mm | 1.5 mm | 1.57 mm | 85 | |
LCBS-L-7-01 | UL94 V-2 | Snap Lock | Natural | 3.2 mm | 11.1 mm | Hole Fix | 3.5 mm | 13.0 mm | 21.5 mm | -40 | #4, M3 | Nylon 6/6 | 10.0 mm | 1.5 mm | 1.57 mm | 85 | |
LCBS-L-8-01 | UL94 V-2 | Snap Lock | Natural | 3.2 mm | 12.7 mm | Hole Fix | 3.5 mm | 13.0 mm | 21.5 mm | -40 | #4, M3 | Nylon 6/6 | 10.0 mm | 1.5 mm | 1.57 mm | 85 |
Per page:
1-6 of 6
1–5 of 6 variants
Per page:
LCBS-L-9-01
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Natural
Hole Diameter A
3.2 mm
LCBS-L-10-01
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Natural
Hole Diameter A
3.2 mm
LCBS-L-6-01
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Natural
Hole Diameter A
3.2 mm
LCBS-L-5-01
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Natural
Hole Diameter A
3.2 mm
Per page:
1–5 of 7
