SR27FTP - Female Threaded Locking PCB Support
Showing 1-10 of 23
Per page:1-10 of 23
Item Code | Material Flammability Standard | Hole A Fix Type | Color | Hole Diameter A | Spacer Length | Hole B Fix Type | Thread Length | Locking Head Height A | Minimum Operating Temperature | Thread Size | Material | Maximum Panel Thickness A | Maximum Operating Temperature | Distance Across Flats | Exposed End Diameter | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
27FTP01406B | UL94 V-2 | Snap Lock | Black | 4.0 mm | 35.71 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | - | - | |
27FTP00250B | UL94 V-2 | Snap Lock | Black | 4.0 mm | 6.35 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 mm | - | |
27FTP00500B | UL94 V-2 | Snap Lock | Black | 4.0 mm | 12.7 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 mm | - | |
27FTP01000B | UL94 V-2 | Snap Lock | Black | 4.0 mm | 25.4 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 mm | - | |
27FTP00625 | UL94 V-2 | Snap Lock | Natural | 4.0 | 15.88 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 | - | |
27FTP00375 | UL94 V-2 | Snap Lock | Natural | 4.0 | 9.53 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 | - | |
27FTP00250 | UL94 V-2 | Snap Lock | Natural | 4.0 | 6.35 mm | Female Thread Fix | 0.312 in | 10.16 mm | -40 °F | #8-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 | - | |
27FTP00500A | UL94 V-2 | Snap Lock | Natural | 4.0 | 12.7 mm | Female Thread Fix | 0.250 in | 10.16 mm | -40 °F | #6-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 | - | |
27FTP00375A | UL94 V-2 | Snap Lock | Natural | 4.0 | 9.53 mm | Female Thread Fix | 0.250 in | 10.16 mm | -40 °F | #6-32 | Nylon 6/6 | 1.6 mm | 185 °F | 7.92 | - |
Per page:
1-10 of 23
1–5 of 23 variants
Per page:
27FTP01406B
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Black
Hole Diameter A
4.0 mm
27FTP00250B
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Black
Hole Diameter A
4.0 mm
27FTP00500B
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Black
Hole Diameter A
4.0 mm
27FTP01000B
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Color
Black
Hole Diameter A
4.0 mm
Per page:
1–5 of 24
