SRCBG - Circuit Board Guide
Showing 1-4 of 4
Per page:1-4 of 4
Item Code | Slot Depth | Color | Maximum Panel Thickness | Maximum Operating Temperature | Clip Width | Accepts Panel Thickness | Material Flammability Standard | Mounting Method | Minimum Operating Temperature | Material | Overall Width | Slot Width | UL/CSA Description | Anchor Length | Minimum Panel Thickness | Height | Clip Height | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CBG-1.5-01 | 1.9 mm | Natural | 1.8 mm | 85 | 8.7 mm | 1.6 mm | UL94 V-2 | Snap In | -40 | Nylon | 14.3 mm | 2.3 mm | UL E70062 | 6.9 mm | 0.8 | 38.1 mm | 3.8 mm | |
CBG-3-01 | 1.9 mm | Natural | 1.8 mm | 85 | 8.7 mm | 1.6 mm | UL94 V-2 | Snap In | -40 | Nylon | 14.3 mm | 2.3 mm | UL E70062 | 6.9 mm | 0.8 | 76.2 mm | 3.8 mm | |
CBG-1-01 | 1.9 mm | Natural | 1.8 mm | 85 | 8.7 mm | 1.6 mm | UL94 V-2 | Snap In | -40 | Nylon | 14.3 mm | 2.3 mm | UL E70062 | 6.9 mm | 0.8 | 25.4 mm | 3.8 mm | |
CBG-2-01 | 1.9 mm | Natural | 1.8 mm | 85 | 8.7 mm | 1.6 mm | UL94 V-2 | Snap In | -40 | Nylon | 14.3 mm | 2.3 mm | UL E70062 | 6.9 mm | 0.8 | 50.8 mm | 3.8 mm |
Per page:
1-4 of 4
1–5 of 4 variants
Per page:
CBG-1.5-01
Slot Depth
1.9 mm
Color
Natural
Maximum Panel Thickness
1.8 mm
Maximum Operating Temperature
85
CBG-3-01
Slot Depth
1.9 mm
Color
Natural
Maximum Panel Thickness
1.8 mm
Maximum Operating Temperature
85
CBG-1-01
Slot Depth
1.9 mm
Color
Natural
Maximum Panel Thickness
1.8 mm
Maximum Operating Temperature
85
CBG-2-01
Slot Depth
1.9 mm
Color
Natural
Maximum Panel Thickness
1.8 mm
Maximum Operating Temperature
85
