Item Code | Band Width | Material | Mount Style | Nut Material | Pitch/TPI | Bolt Material | Bolt Size | Color | Nut Insert Material | SAE Code | Nut Size (Seed) | Max. Hose Diameter | Min. Hose Diameter | Grade | Nut Shape | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TBC108A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 108 | 7/16 in | 4.562 in | 4.250 in | 301 AISI | Hexagonal | |
TBC100A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 100 | 7/16 in | 4.312 in | 4.000 in | 301 AISI | Hexagonal | |
TBC116A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 116 | 7/16 in | 4.812 in | 4.500 in | 301 AISI | Hexagonal | |
TBC156A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 156 | 7/16 in | 6.062 in | 5.750 in | 301 AISI | Hexagonal | |
TBC172A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 172 | 7/16 in | 6.562 in | 6.250 in | 301 AISI | Hexagonal | |
TBC124A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 124 | 7/16 in | 5.062 in | 4.750 in | 301 AISI | Hexagonal | |
TBC28A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 28 | 7/16 in | 1.937 in | 1.750 in | 301 AISI | Hexagonal | |
TBC148A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 148 | 7/16 in | 5.812 in | 5.500 in | 301 AISI | Hexagonal | |
TBC17A | 0.750 in | Stainless Steel | Slip-On | Stainless Steel | 28 TPI | Stainless Steel | 1/4-28 | Natural | Nylon | 60 | 7/16 in | 1.875 in | 1.625 in | 301 AISI | Hexagonal |
Band Width
0.750 in
Material
Stainless Steel
Mount Style
Slip-On
Nut Material
Stainless Steel
Band Width
0.750 in
Material
Stainless Steel
Mount Style
Slip-On
Nut Material
Stainless Steel
Band Width
0.750 in
Material
Stainless Steel
Mount Style
Slip-On
Nut Material
Stainless Steel
Band Width
0.750 in
Material
Stainless Steel
Mount Style
Slip-On
Nut Material
Stainless Steel
