SRSC - Straight Masking Caps
Showing 1-10 of 149
Per page:1-10 of 149
Item Code | Color | Inside Height | Hardness | Cap Inside Diameter | Fitting Style | Maximum Temperature | Material | Overall Diameter | Thread Size | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|
SC003505A | Natural | 0.500 in | 55 ± 5 (Shore A) | 0.035 in | Push-Fit | 600 °F | Silicone | 0.130 in | - | |
SC004007B | Black | 0.750 in | 55 ± 5 (Shore A) | 0.040 in | Push-Fit | 425 °F | EPDM | 0.130 in | - | |
SC007010B | Black | 1.000 in | 55 ± 5 (Shore A) | 0.070 in | Push-Fit | 425 °F | EPDM | 0.160 in | M2, #2-56 | |
SC008007A | Natural | 0.750 in | 55 ± 5 (Shore A) | 0.080 in | Push-Fit | 600 °F | Silicone | 0.200 in | - | |
SC004007A | Natural | 0.750 in | 55 ± 5 (Shore A) | 0.040 in | Push-Fit | 600 °F | Silicone | 0.130 in | - | |
SC006207C | Black | 0.750 in | 55 ± 5 (Shore A) | 0.062 in | Push-Fit | 425 °F | EPDM | 0.152 in | - | |
SC010010A | Natural | 1.000 in | 55 ± 5 (Shore A) | 0.100 in | Push-Fit | 600 °F | Silicone | 0.200 in | #4-40 | |
SC006207A | Natural | 0.750 in | 55 ± 5 (Shore A) | 0.062 in | Push-Fit | 600 °F | Silicone | 0.152 in | - | |
SC002005B | Black | 0.500 in | 55 ± 5 (Shore A) | 0.020 in | Push-Fit | 425 °F | EPDM | 0.140 in | - |
Per page:
1-10 of 149
1–5 of 149 variants
Per page:
SC003505A
Color
Natural
Inside Height
0.500 in
Hardness
55 ± 5 (Shore A)
Cap Inside Diameter
0.035 in
SC004007B
Color
Black
Inside Height
0.750 in
Hardness
55 ± 5 (Shore A)
Cap Inside Diameter
0.040 in
SC007010B
Color
Black
Inside Height
1.000 in
Hardness
55 ± 5 (Shore A)
Cap Inside Diameter
0.070 in
SC008007A
Color
Natural
Inside Height
0.750 in
Hardness
55 ± 5 (Shore A)
Cap Inside Diameter
0.080 in
Per page:
1–5 of 150
