SR22MWCA - Wire Saddles on Adhesive Base
Showing 1-3 of 3
Per page:1-3 of 3
Item Code | Color | Inside Height | Material | Base Width | Base Length | Clip Height | Type | Mount Type | Inside Width | Material Flammability Standard | Clip Width | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
22MWCA1870375 | Natural | 2.3 mm | Nylon 6/6 | 9.5 mm | 9.5 mm | 7.0 mm | 2 | Adhesivo | 4.7 mm | UL94 V-2 | - | |
22MWCA350500 | Natural | 4.2 mm | Nylon 6/6 | 12.7 mm | 12.7 mm | 13.3 mm | 1 | Adhesivo | 8.9 mm | UL94 V-2 | 12.7 mm | |
22MWCA350750TAB | Natural | 12.7 mm | Nylon 6/6 | 19.1 mm | 19.1 mm | 13.3 mm | 1 | Adhesivo | 8.9 mm | UL94 V-2 | - |
Per page:
1-3 of 3
1–4 of 3 variants
Per page:
22MWCA1870375
Color
Natural
Inside Height
2.3 mm
Material
Nylon 6/6
Base Width
9.5 mm
22MWCA350500
Color
Natural
Inside Height
4.2 mm
Material
Nylon 6/6
Base Width
12.7 mm
22MWCA350750TAB
Color
Natural
Inside Height
12.7 mm
Material
Nylon 6/6
Base Width
19.1 mm
