SRTL - Twist Locks
Item Code | Maximum Cable Bundle Diameter | Color | Minimum Cable Bundle Diameter | UL/CSA Description | Overall Height | Maximum Operating Temperature | Material Flammability Standard | Mounting Method | Minimum Operating Temperature | Material | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|
TL-600 | 16.5 mm | Natural | 14.0 mm | UL E70062 | 33.7 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-450 | 12.7 mm | Natural | 10.2 mm | UL E70062 | 30.5 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-350 | 10.2 mm | Natural | 7.6 mm | UL E70062 | 26.1 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-250 | 7.6 mm | Natural | 5.1 mm | UL E70062 | 22.9 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-950 | 25.4 mm | Natural | - | UL E70062 | 43.4 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-750 | 20.3 mm | Natural | 17.8 mm | UL E70062 | 39.4 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-1125 | 30.2 mm | Natural | - | UL E70062 | 55.6 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-1500 | 39.7 mm | Natural | - | UL E70062 | 74.4 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 | |
TL-1750 | 46.0 mm | Natural | - | UL E70062 | 87.6 | 85 °C | UL94 V-2 | Twist Lock | -40 °C | Nylon 6/6 |
TL-600
Maximum Cable Bundle Diameter
16.5 mm
Color
Natural
Minimum Cable Bundle Diameter
14.0 mm
UL/CSA Description
UL E70062
TL-450
Maximum Cable Bundle Diameter
12.7 mm
Color
Natural
Minimum Cable Bundle Diameter
10.2 mm
UL/CSA Description
UL E70062
TL-350
Maximum Cable Bundle Diameter
10.2 mm
Color
Natural
Minimum Cable Bundle Diameter
7.6 mm
UL/CSA Description
UL E70062
TL-250
Maximum Cable Bundle Diameter
7.6 mm
Color
Natural
Minimum Cable Bundle Diameter
5.1 mm
UL/CSA Description
UL E70062
