Item Code | Maximum Cable Bundle Diameter | Color | Base Width | Base Height | Overall Height | Maximum Operating Temperature | Material Flammability Standard | Mounting Method | Minimum Operating Temperature | Material | Minimum Cable Bundle Diameter | Overall Width | Spacer Length | Overall Length | UL/CSA Description | Base Length | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
KLBS-3508-01A | 10.2 mm | Natural | 25.4 | 12.7 mm | 38.9 | 85 °C | UL94 V-2 | Adhesive | -40 °C | Nylon 6/6 | 7.6 mm | 25.4 mm | 12.7 | 25.4 mm | UL E71558 | 25.4 | |
KLBS-35016-01A | 10.2 mm | Natural | 25.4 | 25.4 mm | 51.6 | 85 °C | UL94 V-2 | Adhesive | -40 °C | Nylon 6/6 | 7.6 mm | 25.4 mm | 25.4 | 25.4 mm | UL E71558 | 25.4 | |
KLBS-35012-01A | 10.2 mm | Natural | 1.000 in | - | 1.781 | 85 °C | UL94 V-2 | Adhesive | -40 °C | Nylon 6/6 | 7.6 mm | - | 0.750 in | - | UL E71558 | 1.000 in | |
KLBS-350-401A | 10.2 mm | Natural | 1.000 in | 6.4 mm | 1.781 | 85 °C | UL94 V-2 | Adhesive | -40 °C | Nylon 6/6 | 7.6 mm | 25.4 mm | 0.250 in | 25.4 mm | UL E71558 | 1.000 in |
Maximum Cable Bundle Diameter
10.2 mm
Color
Natural
Base Width
25.4
Base Height
12.7 mm
Maximum Cable Bundle Diameter
10.2 mm
Color
Natural
Base Width
25.4
Base Height
25.4 mm
Maximum Cable Bundle Diameter
10.2 mm
Color
Natural
UL/CSA Description
UL E71558
Base Width
1.000 in
Maximum Cable Bundle Diameter
10.2 mm
Color
Natural
Base Width
1.000 in
Base Height
6.4 mm
