Item Code | Material Flammability Standard | Color | Minimum Cable Bundle Diameter | Roll Length | Tool | Maximum Operating Temperature | Melting Point | Maximum Cable Bundle Diameter | Minimum Operating Temperature | Material | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|
FRBS-03 | UL94 V-0 | Black;Grey | 1.0 mm | 1000.0 | Hot Knife | 150 °C | 240 ±10 °C | 6.0 mm | -50 °C | PES | |
FRBS-06 | UL94 V-0 | Black;Grey | 3.0 mm | 500.0 | Hot Knife | 150 °C | 240 ±10 °C | 9.0 mm | -50 °C | PES | |
FRBS-08 | UL94 V-0 | Black;Grey | 5.0 mm | 350.0 | Hot Knife | 150 °C | 240 ±10 °C | 12.0 mm | -50 °C | PES | |
FRBS-12 | UL94 V-0 | Black;Grey | 8.0 mm | 350.0 | Hot Knife | 150 °C | 240 ±10 °C | 20.0 mm | -50 °C | PES | |
FRBS-20 | UL94 V-0 | Black;Grey | 18.0 mm | 200.0 | Hot Knife | 150 °C | 240 ±10 °C | 33.0 mm | -50 °C | PES | |
FRBS-10 | UL94 V-0 | Black;Grey | 7.0 mm | 350.0 | Hot Knife | 150 °C | 240 ±10 °C | 17.0 mm | -50 °C | PES | |
FRBS-14 | UL94 V-0 | Black;Grey | 10.0 mm | 250.0 | Hot Knife | 150 °C | 240 ±10 °C | 27.0 mm | -50 °C | PES | |
FRBS-30 | UL94 V-0 | Black;Grey | 30.0 mm | 100.0 | Hot Knife | 150 °C | 240 ±10 °C | 60.0 mm | -50 °C | PES | |
FRBS-16 | UL94 V-0 | Black;Grey | 14.0 mm | 200.0 | Hot Knife | 150 °C | 240 ±10 °C | 30.0 mm | -50 °C | PES |
Material Flammability Standard
UL94 V-0
Color
Black;Grey
Minimum Cable Bundle Diameter
1.0 mm
Roll Length
1000.0
Material Flammability Standard
UL94 V-0
Color
Black;Grey
Minimum Cable Bundle Diameter
3.0 mm
Roll Length
500.0
Material Flammability Standard
UL94 V-0
Color
Black;Grey
Minimum Cable Bundle Diameter
5.0 mm
Roll Length
350.0
Material Flammability Standard
UL94 V-0
Color
Black;Grey
Minimum Cable Bundle Diameter
8.0 mm
Roll Length
350.0
