SRPGSB - Closed Insulation Bushings
Showing 1-9 of 9
Per page:1-9 of 9
Item Code | Open/Closed | Material Flammability Standard | Color | Cable Diameter | Overall Height | Maximum Operating Temperature | Type | Minimum Operating Temperature | Material | Overall Diameter | Inside Diameter | UL/CSA Description | Maximum Panel Thickness | Head Diameter | Mounting Hole Diameter | Head Height | Minimum Panel Thickness | Panel Thickness | Height Under Flange | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PGSB-43 | Closed | UL94 V-2 | Black | 47.0 mm | 18.2 | 185 °F | Closed | -40 °F | Nylon 6/6 | 63.0 mm | 47.0 | UL E320906 | 1.57 | 63.0 | 57.2 mm | 1.6 mm | 0.250 in | 6.4 mm | 16.7 mm | |
PGSB-1013 | Closed | UL94 V-2 | Black | 10.2 mm | 9.0 | 185 °F | Closed | -40 °F | Nylon 6/6 | 15.0 mm | 10.2 | UL E320906 | 3.0 | 15.0 | 13.0 mm | 1.3 mm | 0.8 | - | - | |
PGSB-1822 | Closed | UL94 V-2 | Black | 18.2 mm | 11.5 | 185 °F | Closed | -40 °F | Nylon 6/6 | 24.8 mm | 18.2 | UL E320906 | 2.3 | 24.8 | 22.0 mm | 1.5 mm | 0.9 | - | - | |
PGSB-1519 | Closed | UL94 V-2 | Black | 15.3 mm | 11.0 | 185 °F | Closed | -40 °F | Nylon 6/6 | 21.7 mm | 15.3 | UL E320906 | 3.0 | 21.7 | 19.0 mm | 1.5 mm | 1.3 | - | - | |
PGSB-2428 | Closed | UL94 V-2 | Black | 24.0 mm | 11.2 | 185 °F | Closed | -40 °F | Nylon 6/6 | 31.5 mm | 24.0 | UL E320906 | 3.3 | 31.5 | 28.0 mm | 1.5 mm | 1.0 | - | - | |
PGSB-0710 | Closed | UL94 V-2 | Black | 7.2 mm | 6.6 | 85 | Closed | -40 | Nylon 6/6 | 12.0 mm | 7.2 | UL E320906 | 1.6 | 12.0 | 10.0 mm | 1.3 mm | 0.8 | - | - | |
PGSB-2634 | Closed | UL94 V-2 | Black | 26.2 mm | 11.5 | 185 °F | Closed | -40 °F | Nylon 6/6 | 38.0 mm | 26.2 | UL E320906 | 3.2 | 38.0 | 34.2 mm | 1.5 mm | 1.0 | - | - | |
PGSB-2530 | Closed | UL94 V-2 | Black | 25.0 mm | 11.5 | 185 °F | Closed | -40 °F | Nylon 6/6 | 33.5 mm | 25.0 | UL E320906 | 3.1 | 33.5 | 30.0 mm | 1.8 mm | 1.0 | - | - | |
BSI047A | Closed | UL94 V-2 | Black | - | 18.2 mm | 185 °F | Closed, Insulation | -40 °F | Nylon 6/6 | - | 62.7 mm | - | 6.4 mm | 3.160 in | 76.2 mm | - | 0.250 in | - | - |
Per page:
1-9 of 9
1–5 of 9 variants
Per page:
PGSB-43
Open/Closed
Closed
Material Flammability Standard
UL94 V-2
Color
Black
Cable Diameter
47.0 mm
PGSB-1013
Open/Closed
Closed
Material Flammability Standard
UL94 V-2
Color
Black
Cable Diameter
10.2 mm
PGSB-1822
Open/Closed
Closed
Material Flammability Standard
UL94 V-2
Color
Black
Cable Diameter
18.2 mm
PGSB-1519
Open/Closed
Closed
Material Flammability Standard
UL94 V-2
Color
Black
Cable Diameter
15.3 mm
Per page:
1–5 of 10
