SRMCCG - Metal Cushioned Grommets
Showing 1-8 of 8
Per page:1-8 of 8
Item Code | Material Flammability Standard | Color | Hardness | Overall Width | UL/CSA Description | Roll Length | Coating | Style | Overall Height | Type | Minimum Operating Temperature | Material | Maximum Operating Temperature | Channel Height | Distance Between Slots | Maximum Panel Thickness | Dielectric Strength | Grade | Military Specification | Base Height | Minimum Panel Thickness | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MCCGF-2N | UL94 V-0 | Black | 60 Shore D | 4.8 mm | UL E320906 | 30.48 m | Nylon 11 | Serrated | 5.8 mm | Flexible | -40 °C | Stainless Steel | - | - | - | - | - | - | - | - | - | |
MCCGF-1N | UL94 V-0 | Black | 60 Shore D | 4.8 mm | UL E320906 | 30.48 m | Nylon 11 | Serrated | 5.8 mm | Flexible | -40 °C | Stainless Steel | - | - | - | - | - | - | - | - | - | |
MCCGF-3N | UL94 V-0 | Black | 60 Shore D | 4.8 mm | UL E320906 | 30.48 m | Nylon 11 | Serrated | 5.8 mm | Flexible | -40 °C | Stainless Steel | - | - | - | - | - | - | - | - | - | |
MCCG-1N | UL94 V-0 | Black | 60 Shore D | 4.8 mm | UL E320906 | 30.48 m | Nylon 11 | - | 5.8 mm | Flexible | -40 °C | Stainless Steel | 85 °C | - | - | - | - | - | - | - | - | |
MCCG-2N | UL94 V-0 | Black | 60 Shore D | 4.8 | UL E320906 | 30.0 | Nylon 11 | - | 5.8 | - | -40 °C | Stainless Steel | 140 °C | 4.5 mm | 3.8 mm | 1.4 mm | 1000 V @ 50 Hz | AISI 304 | MIL-STD-202, MIL-STD-1344 | 1.3 mm | 1.1 mm | |
MCCG-6N | UL94 V-0 | Black | 60 Shore D | 5.8 | UL E320906 | 30.48 | Nylon 11 | - | 5.8 | - | -40 °C | Stainless Steel | 140 °C | 4.5 mm | 3.8 mm | 3.3 mm | 1500 V @ 60 Hz | AISI 304 | MIL-STD-202, MIL-STD-1344 | 1.3 mm | 2.9 mm | |
MCCG-4N | UL94 V-0 | Black | 60 Shore D | 5.8 | UL E320906 | 30.0 | Nylon 11 | - | 5.8 | - | -40 °C | Stainless Steel | 140 °C | 4.5 mm | 3.8 mm | 2.3 mm | 1000 V @ 50 Hz | AISI 304 | MIL-STD-202, MIL-STD-1344 | 1.3 mm | 1.7 mm | |
MCCG-3N | UL94 V-0 | Black | 60 Shore D | 4.8 | UL E320906 | 30.0 | Nylon 11 | - | 5.8 | - | -40 °C | Stainless Steel | 140 °C | 4.5 mm | 3.8 mm | 1.7 mm | 1000 V @ 50 Hz | AISI 304 | MIL-STD-202, MIL-STD-1344 | 1.3 mm | 1.4 mm |
Per page:
1-8 of 8
1–5 of 8 variants
Per page:
MCCGF-2N
Material Flammability Standard
UL94 V-0
Color
Black
Hardness
60 Shore D
Overall Width
4.8 mm
MCCGF-1N
Material Flammability Standard
UL94 V-0
Color
Black
Hardness
60 Shore D
Overall Width
4.8 mm
MCCGF-3N
Material Flammability Standard
UL94 V-0
Color
Black
Hardness
60 Shore D
Overall Width
4.8 mm
MCCG-1N
Material Flammability Standard
UL94 V-0
Color
Black
Hardness
60 Shore D
Overall Width
4.8 mm
Per page:
1–5 of 9
