SRFCLC - Flat Cable Loop Clips
Showing 1-2 of 2
Per page:1-2 of 2
Item Code | Color | Maximum Operating Temperature | Type | Inside Width | Material Flammability Standard | Mounting Method | Minimum Operating Temperature | Material | Overall Length | UL/CSA Description | Base Length | Overall Width | Cable Width | Overall Diameter | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
FCLC | Natural | 85 °C | Loop | 63.5 | UL94 V-2 | No Mounting | -40 °C | Nylon 6/6 | 76.2 mm | UL70062 | 76.2 | - | - | - | |
FCLCS | Natural | 85 °C | Loop | 1.50 in | UL94 V-2 | No Mounting | -40 °C | Nylon 6/6 | 50.8 mm | UL70062 | 2.00 in | 6.4 mm | 38.1 mm | 5.8 mm |
Per page:
1-2 of 2
1–3 of 2 variants
Per page:
FCLC
Color
Natural
Maximum Operating Temperature
85 °C
Type
Loop
Inside Width
63.5
FCLCS
Color
Natural
Overall Width
6.4 mm
Cable Width
38.1 mm
Maximum Operating Temperature
85 °C
