Item Code | Color | Inside Height | Overall Thickness | Mounting Hole Width | Maximum Operating Temperature | Mounting Hole Length | Inside Width | Mounting Method | Minimum Operating Temperature | Material | Overall Width | Distance Between Fixing Holes | Overall Length | UL/CSA Description | Anchor Length | Maximum Panel Thickness | Inside Locking Head Width | Base Length | Minimum Panel Thickness | Overall Height | Clip Height | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
FCCS-4 | Natural | 3.7 | 1.2 mm | 2.6 mm | 110 °C | 5.3 mm | 5.0 | Push In | -40 °C | Nylon 6/6 | 7.0 mm | 45.0 | 57.0 mm | UL E70062 | 1.5 mm | 1.6 | 5.0 mm | 2.240 in | 0.8 | 7.3 | 5.8 mm | |
FCCS-5 | Natural | 3.7 | 1.5 mm | 2.6 mm | 110 °C | 5.3 mm | 5.0 | Push In | -40 °C | Nylon 6/6 | 7.0 mm | 60.0 | 72.0 mm | UL E70062 | 1.5 mm | 1.6 | 5.0 mm | 2.830 in | 0.8 | 7.3 | 5.8 mm | |
FCCS-3 | Natural | 3.7 | 1.0 mm | 2.6 mm | 110 °C | 5.3 mm | 5.0 | Push In | -40 °C | Nylon 6/6 | 7.0 mm | 35.0 | 47.0 mm | UL E70062 | 1.5 mm | 1.6 | 5.0 mm | 1.850 in | 0.8 | 7.3 | 5.8 mm | |
FCCS-1 | Natural | 3.4 | 0.8 mm | 2.6 mm | 110 °C | 5.3 mm | 5.0 | Push In | -40 °C | Nylon 6/6 | 7.0 mm | 15.0 | 27.0 mm | UL E70062 | 1.5 mm | 1.6 | 5.0 mm | 1.060 in | 0.8 | 7.3 | 5.8 mm | |
FCCS-2 | Natural | 3.7 | 1.0 mm | 2.6 mm | 110 °C | 5.3 mm | 5.0 | Push In | -40 °C | Nylon 6/6 | 7.0 mm | 30.0 | 42.0 mm | UL E70062 | 1.5 mm | 1.6 | 5.0 mm | 1.650 in | 0.8 | 7.3 | 5.8 mm |
Color
Natural
Inside Height
3.7
Overall Thickness
1.2 mm
Mounting Hole Width
2.6 mm
Color
Natural
Inside Height
3.7
Overall Thickness
1.5 mm
Mounting Hole Width
2.6 mm
Color
Natural
Inside Height
3.7
Overall Thickness
1.0 mm
Mounting Hole Width
2.6 mm
Color
Natural
Inside Height
3.4
Overall Thickness
0.8 mm
Mounting Hole Width
2.6 mm
