SRUMS - Universal Mounting Straps
Showing 1-5 of 5
Per page:1-5 of 5
Item Code | Color | Hole Diameter | UL/CSA Description | Cord Holder Width | Base Width | Mounting Hole Diameter | Adhesive Material | Cable Diameter | Maximum Operating Temperature | Clip Width | Material Flammability Standard | Mounting Method | Minimum Operating Temperature | Thread Size | Material | Base Length | Cable Width | Clip Height | Maximum Compatible Cable Diameter | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
UMS-24-45A-RT | Black | 0.204 in | UL E41938 | 16.5 mm | 1.100 in | 5.1 mm | Acrylic | 38.1 mm | 85 | 27.9 mm | UL94 HB | Adhesive | -40 | M4 | Nylon 6/6 | 1.100 in | 12.7 mm | 4.6 mm | - | |
UMS-32-45A-RT | Black | 0.204 in | UL E41938 | 16.5 mm | 1.100 in | 5.1 mm | Acrylic | 50.8 mm | 85 | 27.9 mm | UL94 HB | Adhesive | -40 | M4 | Nylon 6/6 | 1.100 in | 12.7 mm | 4.6 mm | - | |
UMS-16-45A-RT | Black | 0.204 in | UL E41938 | 16.5 mm | 1.100 in | 5.1 mm | Acrylic | 25.4 mm | 85 | 27.9 mm | UL94 HB | Adhesive | -40 | M4 | Nylon 6/6 | 1.100 in | 12.7 mm | 4.6 mm | - | |
UMS-32-45 | Black | 0.204 in | UL E41938 | 16.5 mm | 1.100 in | 5.1 mm | - | 50.8 mm | 85 | 27.9 mm | UL94 HB | Adhesive | -40 | M4 | Nylon 6/6 | 1.100 in | 12.7 mm | 4.6 mm | 2.000 in | |
UMS-24-45 | Black | 0.201 in | UL E41938 | 16.5 mm | 1.100 in | 5.1 mm | - | 38.1 mm | 85 | 27.9 mm | UL94 HB | Adhesive | -40 | M4 | Nylon 6/6 | 1.100 in | 12.7 mm | 4.6 mm | 1.500 in |
Per page:
1-5 of 5
1–5 of 5 variants
Per page:
UMS-24-45A-RT
Color
Black
Hole Diameter
0.204 in
UL/CSA Description
UL E41938
Cord Holder Width
16.5 mm
UMS-32-45A-RT
Color
Black
Hole Diameter
0.204 in
UL/CSA Description
UL E41938
Cord Holder Width
16.5 mm
UMS-16-45A-RT
Color
Black
Hole Diameter
0.204 in
UL/CSA Description
UL E41938
Cord Holder Width
16.5 mm
UMS-32-45
Color
Black
Hole Diameter
0.204 in
UL/CSA Description
UL E41938
Cord Holder Width
16.5 mm
Per page:
1–5 of 6
