SRCT - Nylon Locking Cable Ties
Item Code | Material Flammability Standard | Maximum Cable Bundle Diameter | Color | Maximum Service Temperature | Military Specification | Overall Width | Hole Type | Coating | Strap Width | Maximum Loop Tensile Strength | Minimum Service Temperature | Material | Minimum Loop Tensile Strength | Overall Length | UL/CSA Description | Tooth Material | Classification | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CT071B | UL94 V-2 | 4.330 in | Black | 85 °C | MS-3367, MIL-S-23190E | 0.250 in | No Screw Hole | Uncoated | 0.252 in | 100.0 lb | 40 °C | Nylon 6/6 | 100 lbs | 15.000 | UL 181B-C | Nylon | Heavy Duty | |
CT069B | UL94 V-2 | 3.460 in | Black | 85 °C | MS-3367, MIL-S-23190E | 0.300 in | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 11.750 | UL 181B-C | Nylon | Heavy Duty | |
CT068B | UL94 V-2 | 3.070 in | Black | 85 °C | MS-3367, MIL-S-23190E | 0.299 | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 11.000 | UL 181B-C | Nylon | Heavy Duty | |
CT065B | UL94 V-2 | 1.540 | Black | 85 °C | MS-3367, MIL-S-23190E | 0.300 in | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 6.000 | UL 181B-C | Nylon | Heavy Duty | |
CT071A | UL94 V-2 | 4.330 in | Natural | 85 °C | MS-3367, MIL-S-23190E | 0.250 in | No Screw Hole | Uncoated | 0.252 in | 100.0 lb | 40 °C | Nylon 6/6 | 100 lbs | 15.000 | UL 181B-C | Nylon | Heavy Duty | |
CT067B | UL94 V-2 | 2.600 in | Black | 85 °C | MS-3367, MIL-S-23190E | 0.300 in | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 9.437 | UL 181B-C | Nylon | Heavy Duty | |
CT072B | UL94 V-2 | 4.330 in | Black | 85 °C | MS-3367, MIL-S-23190E | 0.300 in | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 15.000 | UL 181B-C | Nylon | Heavy Duty | |
CT066B | UL94 V-2 | 2.170 in | Black | 85 °C | MS-3367, MIL-S-23190E | 0.300 in | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 8.000 | UL 181B-C | Nylon | Heavy Duty | |
CT065A | UL94 V-2 | 1.540 | Natural | 85 °C | MS-3367, MIL-S-23190E | 0.300 in | No Screw Hole | Uncoated | 0.299 in | 120.0 lb | 40 °C | Nylon 6/6 | 120 lbs | 6.000 | UL 181B-C | Nylon | Heavy Duty |
CT071B
Material Flammability Standard
UL94 V-2
Maximum Cable Bundle Diameter
4.330 in
Color
Black
Maximum Service Temperature
85 °C
CT069B
Material Flammability Standard
UL94 V-2
Maximum Cable Bundle Diameter
3.460 in
Color
Black
Maximum Service Temperature
85 °C
CT068B
Material Flammability Standard
UL94 V-2
Maximum Cable Bundle Diameter
3.070 in
Color
Black
Maximum Service Temperature
85 °C
CT065B
Material Flammability Standard
UL94 V-2
Maximum Cable Bundle Diameter
1.540
Color
Black
Maximum Service Temperature
85 °C
