SRSK 015 - Retaining Polyethylene Washer
Showing 1-10 of 13
Per page:1-10 of 13
Item Code | Screw Size | Color | Material | Inside Diameter | Thickness | Tooth Location | Style | Outside Diameter | Overall Height | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|
015002500503 | M2.5 | Red | LDPE - PIR | 2.7 | 1.1 | Internal | 1 | 6.5 | - | |
015102500203 | M2.5 | Gray | LDPE - PIR | 2.7 | 1.5 | Internal | 1 | 5.0 | - | |
015006000503 | M6 | Red | LDPE - PIR | 6.4 | 1.6 | Internal | 1 | 12.0 | - | |
015005000503 | M5 | Red | LDPE - PIR | 5.3 | 1.4 | Internal | 1 | 11.0 | - | |
015205008703 | M5 | Blue | LDPE - PIR | 5.3 | 1.0 | Internal | 1 | 10.0 | - | |
015105000203 | M5 | Gray | LDPE - PIR | 5.3 | 2.5 | Internal | 1 | 8.5 | - | |
015008000503 | M7 | Red | LDPE - PIR | 8.4 | 2.0 | Internal | 1 | 17.0 | - | |
015202508703 | M2.5 | Blue | LDPE - PIR | 2.7 | 1.0 | Internal | 1 | 5.0 | - | |
015106000203 | M6 | Gray | LDPE - PIR | 6.4 | 2.7 | Internal | 1 | 10.0 | 0.106 in |
Per page:
1-10 of 13
1–5 of 13 variants
Per page:
015002500503
Screw Size
M2.5
Color
Red
Material
LDPE - PIR
Inside Diameter
2.7
015102500203
Screw Size
M2.5
Color
Gray
Material
LDPE - PIR
Inside Diameter
2.7
015006000503
Screw Size
M6
Color
Red
Material
LDPE - PIR
Inside Diameter
6.4
015005000503
Screw Size
M5
Color
Red
Material
LDPE - PIR
Inside Diameter
5.3
Per page:
1–5 of 14
