SR16FWRT - Retaining Flat Washers
Showing 1-10 of 72
Per page:1-10 of 72
Item Code | Color | Material | Thickness | Maximum Inside Diameter | Tooth Location | Material Flammability Standard | Screw Size | Inside Diameter | Minimum Inside Diameter | Style | Outside Diameter | Overall Height | Minimum Outside Diameter | Maximum Outside Diameter | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
16FWRT437032B | Black | Nylon 6/6 | 0.032 in | 0.570 in | Interna | UL94 V-2 | 7/16 in | 0.570 in | 0.410 in | 2 | 1.031 in | - | - | - | |
16FWRT010032B | Black | Nylon 6/6 | 0.032 | 0.277 in | Internal | UL94 V-2 | #10 | 0.277 | 0.177 in | 2 | 0.453 | - | - | - | |
16FWRT006062B | Black | Nylon 6/6 | 0.062 | 0.198 in | Internal | UL94 V-2 | #6 | 0.198 | 0.128 in | 2 | 0.328 | - | - | - | |
16FWRT002032B | Black | Nylon 6/6 | 0.032 | 0.115 in | Internal | UL94 V-2 | #2 | 0.115 | 0.078 in | 2 | 0.203 | - | - | - | |
16FWRT004062B | Black | Nylon 6/6 | 0.062 | 0.156 in | Internal | UL94 V-2 | #4 | 0.156 | 0.102 in | 2 | 0.266 | - | - | - | |
16FWRT006032B | Black | Nylon 6/6 | 0.032 | 0.198 in | Internal | UL94 V-2 | #6 | 0.198 | 0.128 in | 2 | 0.328 | - | - | - | |
16FWRT008032AB | Black | Nylon 6/6 | 0.032 | 0.235 in | Internal | UL94 V-2 | #8 | 0.235 | 0.135 in | 2 | 0.390 | - | - | - | |
16FWRT008045B | Black | Nylon 6/6 | 0.045 | 0.218 in | Internal | UL94 V-2 | #8 | 0.218 | 0.135 in | 2 | 0.453 | - | - | - | |
16FWRT010062AB | Black | Nylon 6/6 | 0.062 | 0.277 in | Internal | UL94 V-2 | #10 | 0.277 | 0.177 in | 2 | 0.500 | - | - | - |
Per page:
1-10 of 72
1–5 of 72 variants
Per page:
16FWRT437032B
Color
Black
Material
Nylon 6/6
Thickness
0.032 in
Maximum Inside Diameter
0.570 in
16FWRT010032B
Color
Black
Material
Nylon 6/6
Thickness
0.032
Maximum Inside Diameter
0.277 in
16FWRT006062B
Color
Black
Material
Nylon 6/6
Thickness
0.062
Maximum Inside Diameter
0.198 in
16FWRT002032B
Color
Black
Material
Nylon 6/6
Thickness
0.032
Maximum Inside Diameter
0.115 in
Per page:
1–5 of 73
