SR62 - Quarter Turn Latches - Wing Knob Lock
Showing 1-3 of 3
Per page:1-3 of 3
Item Code | Color | Housing Height | Head Height | Finish | Key Type | Seal Material | Latch Material | Latch Style | Mounting Hole Length | Mounting Orientation | Housing Material | Handle Type | Mounting Hole Width | Coating | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0622000 | Black | 18.5 mm | 20.0 mm | Black Powder-Coated | No Key | Rubber | Nylon | Cam Latch | 22.2 mm | Universal | Nylon | Wing Knob Handle | 20.2 mm | - | |
0621200 | Black | 18.5 mm | 20.0 mm | Black Powder-Coated | No Key | Rubber | Die Cast Zinc Alloy | Cam Latch | 22.2 mm | Universal | Zinc Alloy | Wing Knob Handle | 20.2 mm | Powder-Coated | |
0621100 | Silver | 18.5 mm | 20.0 mm | Chrome Plated | No Key | Rubber | Die Cast Zinc Alloy | Cam Latch | 22.2 mm | Universal | Zinc Alloy | Wing Knob Handle | 20.2 mm | Chrome-Plated |
Per page:
1-3 of 3
1–4 of 3 variants
Per page:
0622000
Color
Black
Housing Height
18.5 mm
Head Height
20.0 mm
Finish
Black Powder-Coated
0621200
Color
Black
Housing Height
18.5 mm
Head Height
20.0 mm
Coating
Powder-Coated
0621100
Color
Silver
Housing Height
18.5 mm
Head Height
20.0 mm
Coating
Chrome-Plated
