SR995 - Concealed Hinge
Showing 1-6 of 6
Per page:1-6 of 6
Item Code | Door Attachment Length | Material | Overall Width | Overall Length | Door to Frame Clearance | Length to Hole Center | Mounting Hole Diameter | Offset Distance | Hole Centre Distance | Hinge Type | Stud Thread Size | Mounting Method | Removability | Color | Pin Diameter | Mounting Orientation | Mounting Hole Spacing Along Length | Welded Part Material | Overall Leaf Length | Leaf Thickness | Length to Hole Center | Maximum Rotation | Latch Material | DIN Pipe Specification | Type | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
9956320 | 45.0 mm | Zinc-Plated Steel | 28.0 mm | 107.0 mm | 24.5 mm | 18.0 mm | 10.0 mm, 7.0 mm, 6.2 mm | 3.0 mm | 6.0 mm | Bisagra oculta | M6 | Hole | Extraíble | Natural | 6.0 mm | Right- & Left-handed | 25.0 mm | Zinc Alloy | 90.0 mm | 2.5 mm | 12.0 mm | 110 ° | Zinc-Plated Steel | DIN-EN 1774 | 2 | |
9956321 | 45.0 mm | Zinc-Plated Steel | 28.0 mm | 107.0 mm | 24.5 mm | 18.0 mm | 10.0 mm, 7.0 mm, 6.2 mm | 3.0 mm | 6.0 mm | Bisagra oculta | M6 | Stud | Removible | Natural | 6.0 mm | Right- & Left-handed | 25.0 mm | Zinc Alloy | 90.0 mm | 2.5 mm | 12.0 mm | 110 ° | Zinc-Plated Steel | DIN-EN 1774 | 2 | |
99563310 | 45.0 mm | Zinc-Plated Steel | 28.5 mm | 107.0 mm | 24.5 mm | 18.0 mm | 7.0 mm | 3.0 mm | 6.0 mm | Concealed Hinge | M5 | Screw, Weld | Removable | - | 6.0 mm | - | 25.0 mm | Copper Plated | 90.0 mm | 2.5 mm | 12.0 mm | 110 ° | Zinc-Plated Steel | - | 1 | |
99563311 | 45.0 mm | Zinc-Plated Steel | 28.5 mm | 107.0 mm | 24.5 mm | 18.0 mm | 7.0 mm | 3.0 mm | 6.0 mm | Concealed Hinge | M5 | Screw, Weld | Removable | - | 6.0 mm | - | 25.0 mm | Copper Plated | 90.0 mm | 2.5 mm | 12.0 mm | 110 ° | Zinc-Plated Steel | - | 1 | |
99563411 | 45.0 mm | Zinc-Plated Steel | 28.5 mm | 107.0 mm | 24.5 mm | 18.0 mm | 7.0 mm | 3.0 mm | 6.0 mm | Concealed Hinge | M5 | Screw, Weld | Removable | - | 6.0 mm | - | 25.0 mm | Copper Plated | 90.0 mm | 2.5 mm | 12.0 mm | 110 ° | Zinc-Plated Steel | - | 1 | |
99563410 | 45.0 mm | Zinc-Plated Steel | 28.5 mm | 107.0 mm | 24.5 mm | 18.0 mm | 7.0 mm | 3.0 mm | 6.0 mm | Concealed Hinge | M5 | Screw, Weld | Removable | - | 6.0 mm | - | 25.0 mm | Copper Plated | 90.0 mm | 2.5 mm | 12.0 mm | 110 ° | Zinc-Plated Steel | - | 1 |
Per page:
1-6 of 6
1–5 of 6 variants
Per page:
9956320
Door Attachment Length
45.0 mm
Material
Zinc-Plated Steel
Overall Width
28.0 mm
Overall Length
107.0 mm
9956321
Door Attachment Length
45.0 mm
Material
Zinc-Plated Steel
Overall Width
28.0 mm
Overall Length
107.0 mm
99563310
Pin Diameter
6.0 mm
Mounting Hole Spacing Along Length
25.0 mm
Door Attachment Length
45.0 mm
Material
Zinc-Plated Steel
99563311
Pin Diameter
6.0 mm
Mounting Hole Spacing Along Length
25.0 mm
Door Attachment Length
45.0 mm
Material
Zinc-Plated Steel
