SR289 - Concealed Hinges
Showing 1-8 of 8
Per page:1-8 of 8
Item Code | Pin Length | Material | Overall Width | Body Length | Door to Frame Clearance | Mounting Hole Diameter | Pin Material | Mounting Hole Shape | Body Material | Leaf Thickness | Hinge Type | Maximum Rotation | Mounting Method | Removability | Color | Pin Diameter | Mounting Orientation | Mounting Hole Spacing Along Length | Overall Length | Pin Head Height (Seed) | Overall Leaf Length | Finish | Body Coating | Coating | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
289402002 | 84.0 mm | Stainless Steel | 18.0 mm | 59.0 mm | 13.0 mm | 5.1 mm | Stainless Steel | Round | Stainless Steel | 8.5 mm | Spring Loaded Pin Hinge | 135 ° | Screw | Spring Action Removable | Silver | 5.0 mm | Left-Handed | 45.0 mm | 84.0 mm | 14.5 mm | 60.0 mm | Natural | - | - | |
289632002 | 84.0 mm | Steel | 18.0 mm | 59.0 mm | 13.0 mm | 5.1 mm | Steel | Round | Steel | 8.5 mm | Spring Loaded Pin Hinge | 135 ° | Screw, Bolt, Weld | Spring Action Removable | Chrome | 5.0 mm | Left-Handed | 45.0 mm | 84.0 mm | 14.5 mm | 60.0 mm | Zinc-Plated | Zinc-Plated | Zinc-Plated | |
289632001 | 84.0 mm | Steel | 18.0 mm | 59.0 mm | 13.0 mm | 5.1 mm | Steel | Round | Steel | 8.5 mm | Spring Loaded Pin Hinge | 135 ° | Screw | Spring Action Removable | Chrome | 5.0 mm | Right-Handed | 45.0 mm | 84.0 mm | 14.5 mm | 60.0 mm | Zinc-Plated | Zinc-Plated | Zinc-Plated | |
289401001 | 58.5 mm | Stainless Steel | 16.0 mm | 35.0 mm | - | 3.6 mm | Stainless Steel | - | Stainless Steel | - | Spring-Loaded Pin Hinges | 135 ° | Screw, Bolt, Weld | Spring Action Removable | Silver | 4.0 mm | Right-Handed | 19.0 mm | 58.5 mm | 10.5 mm | 32.0 mm | Natural | - | - | |
289402001 | 84.0 mm | Stainless Steel | 18.0 mm | 59.0 mm | - | 5.1 mm | Stainless Steel | - | Stainless Steel | - | Spring-Loaded Pin Hinges | 135 ° | Screw, Bolt, Weld | Spring Action Removable | Silver | 5.0 mm | Right-Handed | 45.0 mm | 84.0 mm | 14.5 mm | 60.0 mm | Natural | - | - | |
289401002 | 58.5 mm | Stainless Steel | 16.0 mm | 35.0 mm | - | 3.6 mm | Stainless Steel | - | Stainless Steel | - | Spring-Loaded Pin Hinges | 135 ° | Screw, Bolt, Weld | Spring Action Removable | Silver | 4.0 mm | Left-Handed | 19.0 mm | 58.5 mm | 10.5 mm | 32.0 mm | Natural | - | - | |
289631001 | 58.5 mm | Steel | 16.0 mm | 35.0 mm | - | 3.6 mm | Steel | - | Steel | - | Spring-Loaded Pin Hinges | 135 ° | Screw, Bolt, Weld | Spring Action Removable | Silver | 4.0 mm | Right-Handed | 19.0 mm | 58.5 mm | 10.5 mm | 32.0 mm | Zinc-Plated | Zinc-Plated | Zinc-Plated | |
289631002 | 58.5 mm | Steel | 16.0 mm | 35.0 mm | - | 3.6 mm | Steel | - | Steel | - | Spring-Loaded Pin Hinges | 135 ° | Screw, Bolt, Weld | Spring Action Removable | Silver | 4.0 mm | Left-Handed | 19.0 mm | 58.5 mm | 10.5 mm | 32.0 mm | Zinc-Plated | Zinc-Plated | Zinc-Plated |
